SKU: 16-82-2645
PDS 8HP95 High Performance Billet Race Torque Converter – 26/45 Stator – AWD 2018-2023 BMW M5 M8 X5M X6M
Upgrade your ZF 8HP95 transmission with the PDS high performance billet race torque converter featuring a 26/45 stator optimized for AWD applications. This unit fits 2018+ BMW M5 F90 M8 F91/F92/F93 X5M G05 and X6M G06 models delivering reliable power handling for high horsepower drag racing and track use. Engineered for seamless torque multiplication and lockup it supports builds over 1000HP with reduced slip and heat buildup.
Key Features
- Billet Front Cover: Forged from high-strength billet material to handle extreme torque loads without flexing or failure during hard launches
- 26/45 Stator Design: Custom stator configuration provides higher stall speeds and efficient fluid coupling tailored for AWD drivetrains in performance BMWs
- Furnace Brazed Fins: Welded impeller and turbine fins ensure maximum durability and heat resistance under prolonged high-RPM operation
- Multi-Disc Lockup Clutch: Aggressive lockup materials enable firm engagement for direct drive efficiency and quicker shifts at the strip
- Precision Balancing: Factory balanced to 1500 RPM for vibration-free performance and extended transmission life
Product Notes
- Designed as a direct replacement for stock 8HP95 torque converters in listed BMW applications
- Requires compatible transmission fluid and proper break-in procedure for peak longevity
- Special order item expect 3-5 business days for processing before shipment
Installation Notes
- Professional installation recommended.
- Flush transmission and replace filter during install to prevent contamination
- Compatible with OEM mounting hardware and flexplate spline count of 27
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2018-2023 | BMW | M5 | Sedan (F90) |
| 2020-2023 | BMW | M8 | Convertible (F91) |
| 2020-2023 | BMW | M8 | Coupe (F92) |
| 2020-2023 | BMW | M8 | Gran Coupe (F93) |
| 2020-2023 | BMW | X5 M | (G05) |
| 2020-2023 | BMW | X6 M | (G06) |
Why Choose PDS?
- Proven in NHRA and track racing with multiple championship builds
- Hand-built in the USA using aerospace-grade materials
- Backed by decades of ZF transmission expertise
Frequently Asked Questions
- Q: Will this fit my 2021 BMW M5 xDrive with 8HP95 transmission?
A: Yes it bolts directly into all 2018-2023 F90 M5 models equipped with the ZF 8HP95 AWD transmission matching OEM spline and pilot specs. - Q: What materials are used in construction?
A: Features billet 6061-T6 aluminum front cover 4340 steel components and TIG-welded brazed fins for maximum strength and heat dissipation. - Q: What is the warranty and break-in process?
A: Comes with a 1-year unlimited mileage warranty. Follow 500-mile break-in with varied RPM driving and fluid changes at 500 and 2500 miles.
Shipping & Handling
- Method: Ground shipping via UPS Freight or FedEx
- Availability: Special order – ships within 3-5 business days
- Packaging: Securely boxed measuring 20 x 20 x 12 inches
- Weight: 55 lbs
