SKU: CRS5137S3D-1
Eagle Subaru EJ20 / EJ25 Connecting Rod (Single Rod) – H-Beam EAG Conrods
Subaru EJ20 or EJ25 engine with the Eagle H-Beam Connecting Rod (Single Rod), precision-engineered for superior strength and performance. Crafted by Eagle, the industry’s leading aftermarket connecting rod manufacturer, this single rod (Part #DBA53919.1S) is forged from high-quality SAE 4340 steel using a two-piece forging process, ensuring exceptional durability and reliability for high-performance and competition applications.
Designed specifically for Subaru EJ20 and EJ25 engines, this H-Beam connecting rod features a fully machined and shot-peened surface, delivering unmatched structural integrity. Equipped with 3/8″ ARP 2000 bolts and alignment sleeves for precise cap location, it’s built to handle up to 750-900 HP at the crank, making it ideal for turbocharged WRX, STI, Forester, and Baja models (2002-2014 Impreza WRX, 2004-2020 STI, and more). The rod is bushed for full-floating piston pins, enhancing performance under extreme conditions.
Key Specifications:
- Material: Forged 4340 Steel
- Center-to-Center Length: 5.137″
- Pin Size: 0.906″
- Pin End Width: 0.842″
- Rod Journal: 2.047″
- Housing Bore: 2.165″
- Big End Width: 0.842″
- Typical Weight: 530g
- Torque Specs: 43 ft-lbs with ARP moly lube ONLY
- Box Dimensions: 8.5″ x 4″ x 1″ (1.3 lbs)
Applications:
- 2002-2014 Subaru Impreza WRX
- 2004-2020 Subaru Impreza WRX STI
- 1998-2012 Subaru Forester (Base, S, X, XT, and more)
- 2003-2006 Subaru Baja (Base, Sport, Turbo)
- 2005-2009 Subaru Legacy GT
- Other EJ18, EJ20, EJ25-equipped models
Product Details:
- SKU: DBA53919.1
- Product Name: EAG Conrods H-Beam – Single
- Born On Date: 12-23-2010
- Manufacturer: Eagle Specialty Products
- Warranty: Manufacturer’s warranty applies
