SKU: K53233
2023-2025 Toyota Sequoia 3-4″ Stage 3 Suspension System
This Stage 3 system features 2023-2025 Toyota Sequoia VS 2.5 Series internal reservoir front coilovers for 4WD models. Adjustable coilovers provide 3-3.75 inches of lift over stock height using OE upper control arms to fit larger wheel and tire setups. ICON vehicle-specific shock length and valving with 2.5-inch shock body deliver up to 40% more travel than stock for better ride quality and performance on and off road.
Key Features
- Front Coilovers (58551DJ x2): 2.5 Series VS with internal reservoirs and adjustable height from 0-3.5 inches for precise lift tuning and increased damping control.
- Rear Shocks (57850R x2): 2.5 Series remote reservoirs prevent fade during extended off-road use and maintain consistent damping.
- Bump Stop Spacers: Aluminum spacers (55168 x2) with extended bumpstops (55177 x1) and upper bumpstops (59416 x4) protect shocks at full compression.
- Increased Travel: 40% more wheel travel than stock components improves articulation and handling over rough terrain.
- Bolt-On Design: Direct fit with OE upper control arms requires no custom fabrication for straightforward upgrade.
Product Notes
- Not compatible with vehicles equipped with adaptive variable suspension (AVS).
- Requires aftermarket wheels and 35-inch tires maximum. minor trimming may be needed for larger sizes.
- Ships as complete kit with all hardware. verify rear bumpstop length with spacers installed.
Installation Notes
- Professional installation recommended.
- Estimated install time 4-6 hours with standard tools and lift.
- OE upper control arms compatible. extended brake lines advised for lifts over 3 inches.
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2023-2025 | Toyota | Sequoia | 4WD (SR5, Limited, Platinum, TRD Pro, Capstone, 1794) |
Why Choose ICON?
- Vehicle Dynamics engineers design shocks specifically for Toyota platforms.
- 6061 aircraft-grade aluminum reservoirs with CDCV technology for adjustable compression.
- Proven in King of the Hammers and Baja racing with millions of off-road miles.
Frequently Asked Questions
- Q: Does this kit fit 2024 Sequoia TRD Pro 4WD?
A: Yes, fully compatible with all 2023-2025 Sequoia 4WD trims including TRD Pro using OE upper control arms. - Q: What materials are used in the reservoirs?
A: CNC-machined 6061 aluminum reservoirs with external fins for maximum heat dissipation and durability. - Q: What warranty coverage applies?
A: ICON provides Limited Lifetime Warranty on shocks against manufacturer defects when installed and used as directed.
Shipping & Handling
- Method: UPS Freight Ground
- Availability: In stock – ships same or next business day
- Packaging: Single oversized box measuring 41 x 17 x 11 inches
- Weight: 92 lbs
Reviews
There are no reviews yet.
